Aerial

TypeRoof

Coefficient of drag

Coefficient Of Drag0.3

Bumpers

ColourPainted

Remote fuel flap release

OperationMechanical

Tyres

Tyre Width175

Tyre Profile65

Tyre Speed RatingT

TypeOther

Extra Load?

Paint

TypeGloss

Door mirrors

TypeInternally Adjustable

ColourBlack

Rear windscreen

WipersConstant

Windscreen wipers

Intermittent WipeVariable

Wheels

Rim TypeSteel

Rim Diameter (in)14

Rim Width (in)5.5

Wheel CoversFull

Spare wheel

TypeSpace Saver

Rim TypeSteel

Non-corrosive body

TypeGalvanised

External dimensions

Overall Length (mm)3640

Overall Width (mm)1660

Overall Height (mm)1500

Wheelbase (mm)2370

Front Track (mm)1440

Rear Track (mm)1420

Kerb To Kerb Turning Circle (mm)9800

Wall To Wall Turning Circle (mm)10400

Overall Length (in)143.3

Overall Width (in)65.4

Overall Height (in)59.1

Wheelbase (in)93.3

Front Track (in)56.7

Rear Track (in)55.9

Kerb To Kerb Turning Circle (ft)32.2

Wall To Wall Turning Circle (ft)34.1

Internal dimensions

Headroom Front (mm)1011

Headroom Rear (mm)954

Leg Room Front (mm)1023

Leg Room Rear (mm)872

Shoulder Room Front (mm)1380

Headroom Front (in)39.8

Headroom Rear (in)37.6

Leg Room Front (in)40.3

Leg Room Rear (in)34.3

Shoulder Room Front (in)54.3

Load compartment capacity

Rear Seat Up To Lower Window (l)205

Rear Seat Down To Lower Window (l)437

Rear Seat Down To Roof (l)950

Rear Seat Up To Lower Window (cu Ft)7.2

Rear Seat Down To Lower Window (cu Ft)15.4

Rear Seat Down To Roof (cu Ft)33.5

Fuel tank

Capacity (l)45

Fuel TypeUnleaded

Capacity (gal)11.9

Weights

Gross Vehicle Weight (kg)1370

Published Kerb Weight (kg)965

Gross Trailer Weight Braked (kg)650

Gross Trailer Weight Unbraked (kg)400

Gross Vehicle Weight (lbs)3020

Published Kerb Weight (lbs)2127

Gross Trailer Weight Braked (lbs)1433

Gross Trailer Weight Unbraked (lbs)882

Disc brakes

Number Of2

Number Of Ventilated Discs2

Headlights

Lens TypeComplex Surface

Bulb Type (low Beam)Halogen

ConfigurationSingle

Headlight control

Internal Height AdjustmentYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Type3-point

OperationReel

Pre-tensionersYes

Rear seat belts

Type3-point

OperationReel

Engine

Cc998

Litres1

Bore69

Stroke66.7

Compression Ratio10

Number Of Cylinders4

ConfigurationIn-line

OrientationTransverse

Valve Gear TypeDouble Overhead Cam

Variable Valve Timing/camshaftYes

Number Of Valves Per Cylinder4

Engine Code1SZ-FE

Emission control level

Standard MetEU4

CO2 Level - G/km Combined134

Catalytic converter

Type3-way

Fuel system

Injection/carburationMulti-point Injection

Fuel

Fuel TypeUnleaded

Generic Primary Fuel TypePetrol

Performance

Maximum Speed (km/h)155

Acceleration 0-62mph (s)13.6

Maximum Speed (mph)96

Power

Measurement StandardEEC

Maximum Power KW48

Maximum Power Hp/PS64

Rpm For Maximum Power (low)6000

Maximum Torque Nm90

Rpm For Maximum Torque (low)4100

Fuel consumption

Urban (l/100km)6.8

Country/highway (l/100km)4.9

Combined (l/100km)5.6

Urban (mpg)35

Country/highway (mpg)48

Combined (mpg)42

Power steering

TypeElectric

Suspension

TypeTorsion Beam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Intermediate service

Distance (km)16093

Period (mths)12

Distance (miles)10000

Main service

Distance (km)32187

Period (mths)24

Distance (miles)20000
